Product Name: Lapcare H510 Motherboard for Intel 10th/11th Gen Processors (LGA 1200)

Brand: Lapcare
Chipset: Intel® H510
Socket: LGA 1200
Form Factor: Micro ATX

Key Features:

• Processor Compatibility: Supports Intel® 10th/11th Gen Core™ i3/i5/i7/i9 processors (Comet Lake-S/Rocket Lake-S LGA 1200)
• Memory Support:
• Dual Channel DDR4 2400/2666/3200 DIMMs
• Supports up to 64GB RAM
• Storage Expansion:
• 4x SATA 3.0 Ports for ample storage
• 2x M.2 Slots for PCIe x4 / SATA 6Gb/s SSDs (Support for 2260/2280 SSD)
• LAN: Realtek® RTL8111E for 1000 Mbps Ethernet connectivity
• Audio: Realtek® 887 6-channel HD audio for superior sound quality

Connectivity:

• USB Ports:
• 4x USB 3.0 ports (2 at back panel, blue, 2 at mid-board)
• 6x USB 2.0 ports (4 at back panel, black, 2 at mid-board)
• Back Panel I/O:
• 1x PS2 MS/KB Port
• 1x HDMI Port
• 1x VGA Port
• 2x USB 3.2 Gen 1 Ports
• 4x USB 2.0 Ports
• 1x RJ45 LAN Port
• 1x 6-CH Audio
• Onboard Pinheaders / Connectors:
• 1x USB 2.0 Header
• 1x USB 3.2 Gen Header
• 1x COM Header
• 1x ESPI Header
• 1x F_Audio Header
• 1x F_Panel Header
• 1x CLR_CMOS Header
• Power Connectors:
• 1x 24 Pin ATX Power Connector
• 1x 8 Pin ATX Power Connector

Slots:

• 1x PCI-E x16 Slot
• 1x PCI-E x1 Slot

Warranty:

• Warranty Summary: 1 Year
• Covered in Warranty: All manufacturing defects
• Not Covered in Warranty: Burnt damage
